DDR3L- Industrial Grade
Key Features: Downward compatible with DDR3, supports 1.35V and 1.5V; DDR3L memory consumes 15% less power than standard DDR3.
| Part Number (PN) | Capacity | Speed |
|---|---|---|
| YX3H2816AB-M9LI | 2 GB | 1866 Mbps |
| YX3H4816AB-M9LI | 4 GB | 1866 Mbps |
Bit Widthx8/x16
Package Size
1Gb: BGA7 8 (7.5mm × 10.6mm × 1.2mm)
BGA96 (7.5mm × 13.5mm × 1.2mm)
2Gb: BGA7 8 (7.5mm × 10.6mm × 1.2mm)
BGA96 (7.5mm × 13.5mm × 1.2mm)
4Gb: BGA7 8 (9.0mm × 10.6mm × 1.2mm)
BGA96 (9.0mm × 13mm × 1.2mm)
Operating Temperature-40℃~95℃
Voltage1.35/1.5V
On Sale
Smart Terminal
Smart TVSet-top boxSmart SpeakerIoT GatewayEducational Electronics
Industry Terminals
Industrial Control EquipmentSecurity SurveillancePOS terminalMedical Devices
Smart Car
Smart CockpitAdvanced Driver Assistance SystemsConnected Vehicle
YuXin DDR3L (1Gb/2Gb/4Gb) is a low-voltage, high-performance embedded DRAM compliant with JEDEC standards, designed for industrial control, IoT, automotive terminals, and embedded motherboards.
JEDEC-compliant low-voltage embedded DRAM with 1Gb~4Gb capacity, ×8/×16 organization, and DDR3L-2133 speed. Drop-in compatible with mainstream platforms—no board redesign needed. At 1.35V, power consumption is reduced by 15% compared to DDR3, with self-refresh current as low as 1mA. ODT signal calibration and Write Leveling for multi-chip parallel operation ensure high-speed stability, making it ideal for industrial control, automotive, and IoT applications.
